HC-B19
HECERE
| Quantity: | |
|---|---|
1.Product Function
● Real-time positioning
● Historical track playback
● Electronic fence
● Long standby
● Smart sleep
● Vibration alarm
● SOS emergency call
● One-click recording
● Remote shutdown
2.Product Feature
● The overall style is exquisite and compact, with strong magnet
● Overall size 21mm*20mm*64mm
● Packing size 11.5cm * 7.5cm * 3.5cm
● 69g machine net weight, 178g with packaging box
● Silver/black
● One button (power button/SOS button)
● Battery 3400mAh
● I/O interface DC charging
● Application for car, trunk, etc.
3.Parameter
Physical Parameter | |
Size | 21mm*20mm*64mm |
Material | Environmental protection ABS material |
Color | Silver/black |
Weight | 69g |
Packing | 11.5cm * 7.5cm * 3.5cm |
Environmental Parameters | |
Working Humidity | 5% to 95% non-solidification |
Working Temperature | -20 ~ 70℃ |
Protection Level | IP67 |
Performance Parameter | |
GSM Frequency band | 850/900/1800/1900MHz |
GPS Chip | MTK6261 |
GPRS Standard | Class12, TCP/IP |
GPS Signal | L1, 1575.42MHz C/A |
GPS Channel Number | 22 channels |
GPS Chip-level Receiving Sensitivity | Tracking: -165dBm, capture: -148dBm |
WIFI Positioning Accuracy | 5～30 meters |
GPS Positioning Accuracy | 5～15 meters |
Base station Positioning Accuracy | 100-1000 meters |
Minimum Standby Current | Less than 0.5 mA |
Average Standby current | Less than 2.5 mA |
GPS Antenna | Built-in high sensitivity ceramic antenna |
3D Gravity Sensor | Support |
Microphone | Support |
Software Parameter | |
Support Operating System | Support Android 2.3 and above, IOS5.0 and above. |
Language Support | Simplified Chinese, English (supports multiple languages) |
Location Mode | GSM, GPRS, GPS, WIFI (Optional) |
Support AGPS | Cold start 26 seconds positioning |
Call Function | SOS call, voice monitoring, remote pickup |
Power management | Ultra-low power consumption power management, intelligent sleep |
One-key Emergency SOS | Automatic dialing |
Electronic Fence | Automatically alarm if it exceeds the set range |
Historical Track | Check the historical track within Three months |
Unlimited upgrade | Software remote upgrade, remote debugging and maintenance, remote setting of parameters |
